FOR AUSTRALIA
Models PKH-2GKLA PLH-3AK PLH-4AKS PLH-5AKS PLH-6AKS
Cooling Capacity W 5,400 7,700 9,700 12,400 14,000
BTU/h 18,400 26,300 33,100 42,300 47,800
Power input kW 2.25 3.32 3.46 4.51 5.07
Current A 10.1 14.6 6.0 6.0 7.7 8.7
Heating Capacity W 6,100 8,400 10,400 14,000 16,100
BTU/h 20,800 28,700 35,500 47,800 54,900
Power input kW 2.26 3.11 3.45 4.46 4.92
Current A 10.1 13.7 5.6 5.9 7.6 8.4
Indoor unit Model name PKH-2GKLA PLH-3AK PLH-4AKS PLH-5AKS PLH-6AKS
Power supply Single, 50Hz, 240V
Outdoor unit Model name PU-2AKA PUH-3VKA PUH-3YKA PUH-4YKSA PUH-5YKSA PUH-6YKSA
Power supply Single, 50Hz, 240V 3phase, 50Hz, 415V
*1 Rating conditions (JIS B 8616)
Cooling Indoor : 27°CDB 19°CWB Outdoor : 35°CDB 24°CWB
Heating Indoor : 20°CDB Outdoor : 7°CDB 6°CWB
*2 Refrigerant piping length (one-way) : 5m
E
5. Specifications
Models PK-1.6GKLD PK-2GKLD PKH-2GKLA PLH-3AK PLH-4AKS PLH-5AKS PLH-6AKS
Cooling Capacity W 3,900 5,600 5,400 7,500 9,500 12,200 13,800
BTU/h 13,300 19,100 18,400 25,600 32,400 41,600 47,100
Power input kW 1.49 2.51 2.19 3.28 3.41 4.47 4.96
Current A 7.0 11.6 10.2 15.5 6.0 6.0 8.1 9.0
Heating Capacity W – – 6,150 8,200 10,200 13,600 15,700
BTU/h – – 21,000 28,000 34,800 46,400 53,600
Power input kW – – 2.21 3.07 3.40 4.41 4.88
Current A – – 10.3 14.5 5.7 6.0 8.0 8.9
Indoor unit Model name PK-1.6GKLD PK-2GKLD PKH-2GKLA PLH-3AK PLH-4AKS PLH-5AKS PLH-6AKS
Power supply Single, 50Hz, 220-240V
Outdoor unit Model name PU-1.6VLJA PU-2VJA PUH-2VKA PUH-3VKA PUH-3YKA PUH-4YKSA PUH-5YKSA PUH-6YKSA
Power supply Single, 50Hz, 220-240V 3phase, 50Hz, 380-415V
*1 Rating conditions (JIS B 8616)
Cooling Indoor : 27°CDB 19°CWB Outdoor : 35°CDB 24°CWB
Heating Indoor : 20°CDB Outdoor : 7°CDB 6°CWB
*2 Figures on indicated voltage
Indoor Single, 50Hz, 220V Outdoor Single, 50Hz, 220V/3Phase, 50Hz, 380V
*3 Refrigerant piping length (one-way) : 5m
Operating range
Indoor Outdoor
Cooling
Upper limit 35°CDB 22.5°CWB 46°CDB
Lower limit 21°CDB 15.5°CWB -5°CDB
Heating
Upper limit 27°CDB 21°CDB 15.5°CWB
Lower limit 21°CDB -8.5°CDB -9.5°CWB
Operating range
Indoor Outdoor
Cooling
Upper limit 35°CDB 22.5°CWB 52°CDB
Lower limit 21°CDB 15.5°CWB -5°CDB
Heating
Upper limit 27°CDB 21°CDB 15.5°CWB
Lower limit 21°CDB -8.5°CDB -9.5°CWB
Models PK-2GKLD PKH-2GKLA PLH-3AK PLH-4AKS PLH-5AKS PLH-6AKS
Cooling Capacity W 4,600 5,100 6,800 9,900 11,000 13,400
BTU/h 16,000 17,400 23,200 33,800 37,500 45,700
Power input kW 3.04 2.90 4.29 5.26 6.78 7.32
EER 5.16 6.00 5.41 6.42 5.54 6.25
Current A 14.0 13.4 19.5 14.8 19.9 21.1
Heating Capacity W – 6,600 9,300 12,100 16,500 17,500
BTU/h – 22,500 31,700 41,300 56,300 59,700
Power input kW – 2.52 3.49 4.21 6.02 6.70
Current A – 11.6 16.4 12.0 18.1 19.3
Indoor unit Model name PK-2GKLD PKH-2GKLA PLH-3AK PLH-4AKS PLH-5AKS PLH-6AKS
Power supply Single, 60Hz, 220V
Outdoor unit Model name PU-2NJA PUH-2NKA PUH-3NKA PUH-4TKSA PUH-5TKSA PUH-6TKSA
Power supply Single, 60Hz, 220V 3phase, 60Hz, 220V
*1 Rating conditions (SSA 385, 386)
Cooling Indoor : 29°CDB 19°CWB Outdoor : 46°CDB 24°CWB
Heating Indoor : 21°CDB Outdoor : 7°CDB 6°CWB
*2 Refrigerant piping length (one-way) : 5m
Operating range
Indoor Outdoor
Cooling
Upper limit 35°CDB 22.5°CWB 46°CDB
Lower limit 21°CDB 15.5°CWB -5°CDB
Heating
Upper limit 27°CDB 21°CDB 15.5°CWB
Lower limit 21°CDB -8.5°CDB -9.5°CWB
