- 5 -
2 Name of each part
1
5
2
6
3
7
9
4
8
10
Condensing unit
■
Single specification (TU85SAE-CNF)
1
Front panel
10
Motor
2
Commercial power socket
11
Dryer
3
Latch
12
Oil filter
4
Reservoir tank
13
Fuel filter
5
Compressor
14
Air cleaner
6
Alternator
15
Control box
7
Engine
16
Main switch
8
Radiator & condenser
17
Label (F-Gas)
9
Sight glass
1
15
2
3
4 5 6 7
16
14
13121110
9
8
17
