Mitsubishi A1SD75M3

5 - 119
MELSEC-A
5 DATA USED FOR POSITIONING CONTROL
When " Pr.1 Unit setting" is "inch"
Da.2
setting value
Value set with peripheral device
(inch)
Value set with sequence program *
1
(
×
10
-5
inch)
ABS Linear 1 : 01
H
ABS Linear 2 : 04
H
Current value change : 11
H
◊
Set the address
–21474.83648 to 21474.83647
◊
Set the address
–2147483648 to 2147483647
INC Linear 1 : 02
H
INC Linear 2 : 05
H
Fixed-dimension feed 1 : 03
H
Fixed-dimension feed 2 : 06
H
◊
Set the movement amount
–21474.83648 to 21474.83647
◊
Set the movement amount
–2147483648 to 2147483647
Forward run speed/position : 0F
H
Reverse run speed/position : 10
H
◊
Set the movement amount
0 to 21474.83647
◊
Set the movement amount
0 to 2147483647
Forward run Speed control : 0D
H
Reverse run Speed control : 0E
H
JUMP command : 20
H
(Setting not required) (Setting not required)
ABS Circular interpolation : 07
H
ABS Circular right : 09
H
ABS Circular left : 0A
H
◊
Set the address
–21474.83648 to 21474.83647
◊
Set the address
–2147483648 to 2147483647
INC Circular interpolation : 08
H
INC Circular right : 0B
H
INC Circular left : 0C
H
◊
Set the movement amount
–21474.83648 to 21474.83647
◊
Set the movement amount
–2147483648 to 2147483647
*
1
Decimal points cannot be used in the sequence program, so input the setting value as an integer.
(The value will be converted into the specified value within the system.)
