Mitsubishi A1SD75M3

5 - 168
MELSEC-A
5 DATA USED FOR POSITIONING CONTROL
5.7 List of control data
5.7.1 System control data
Setting item Setting details
Cd.1
Clock data setting (hour)
•
The clock data (hour) from the PLC CPU is set after the AD75 power is turned
ON.
Cd.2
Clock data setting (minute,
second)
•
The clock data (minute, second) from the PLC CPU is set after the AD75 power
is turned ON.
Cd.3
Clock data writing
•
After setting the clock data in
Cd.1
and
Cd.2
, when setting the data in
Md.5
and
Md.6
as the AD75 clock data, set "1".
•
When the setting is completed, the OS sets "0".
Cd.4
Target axis*
•
Set the axis targeted for reading or writing.
*
Cd.4
to
Cd.8
are data used to transmit the positioning data between the OS memory and buffer memory.
(Refer to section "7.2 Data transmission process".)
