5 - 172
MELSEC-A
5 DATA USED FOR POSITIONING CONTROL
Setting item Setting details
Cd.8
Read/write positioning data
I/F
•
Store the data when reading or writing.
Cd.9
Flash ROM write request
•
Write the OS memory contents into the flash ROM.
•
Set whether the setting data will be initialized or not.
Initialization: Indicates that the setting values of the setting data are returned to
the default values.
Note) After completion of the setting data initialization processing, reset the PLC
CPU or power on the PLC again.
Initialized setting data
Parameter (
Pr.1
to
Pr.150
)
Positioning data (No. 1 to 600)
Positioning start information (No. 7000 to 7010)
Cd.10
Parameter initialization
request
*
Cd.4
to
Cd.8
are data used to transmit the positioning data between the OS memory and buffer memory.
(Refer to section "7.2 Data transmission process".)
To Next Page
