6 SEQUENCE PROGRAM USED FOR POSITIONING CONTROL
*
*
*
No.18 Step operation program
*
*
*
No.19 Skip program
*
*
*
*
*
*
*
*
*
No.20 Teaching program
Positioning to the target position with manual operation
Store the data other than the positioning data interface
address in D40 to D45
<Skip operation command pulse>
<Skip operation command ON storage>
<Skip operation command write>
<Skip complete read>
<Skip operation command storage OFF>
<Teaching command pulse>
<Teaching command hold>
<Positioning data write>
<Axis 1 setting>
<Positioning data No.1 setting>
<Teaching data setting>
<Write request setting>
<Teaching data write>
<Teaching result read>
<Teaching command storage OFF>
<Step operation command pulse>
<Step operation run selection>
<Data No. unit step mode selection>
<Step operation command write>
