2 SYSTEM CONFIGURATION
Specifications list of recommended manual pulse generator
Item Specifications
Model name MR-HDP01
Pulse resolution 25pulse/rev (100 pulse/rev after magnification by 4)
Output method
Voltage-output (power supply voltage -1V or more),
Output current = Max. 20mA
Power supply voltage 4.5 to 13.2VDC
Current consumption 60mA
Life time 100 revolutions (at 200r/min)
Radial load : Max. 19.6N
Permitted axial loads
Thrust load : Max. 9.8N
Operation temperature -10 to 60 (14 to 140 )
Weight 0.4 (0.88) [kg(lb)]
Number of max. revolution Instantaneous Max. 600r/min. normal 200r/min
Pulse signal status 2 signals : A phase, B phase, 90 phase difference
Friction torque 0.1N/m (at 20 (68 ))
