2 SYSTEM CONFIGURATION
2.3 Applicable system
The CPU module and remote I/O station applicable for the AD75 are shown below.
CPU module
AD75
PLC CPU *
1
For AD75M1/AD75M2/AD75M3
For A1SD75M1/
A1SD75M2/
A1SD75M3
ACPU
•
A0J2CPU
•
A0J2HCPU
•
A1CPU
•
A2CPU (-S1)
•
A3CPU
•
A1NCPU
•
A2NCPU (-S1)
•
A3NCPU
•
A3MCPU
•
A3HCPU
•
A2ACPU (-S1)
•
A3ACPU
•
A2UCPU (-S1)
•
A3UCPU
•
A4UCPU
•
A73CPU (-S3) *
2
•
A81CPU
•
A52GCPU
•
A1SCPU
•
A1SJCPU-S3
•
A2SCPU
•
A2ASCPU (-S1)
•
A1SHCPU
•
A2SHCPU
•
A1SJHCPU
•
A2USHCPU-S1
•
A1SCPU
•
A1SJCPU (-S3)
•
A2SCPU
•
A2ASCPU (-S1)
•
A52GCPU
•
A1SHCPU
•
A2SHCPU
•
A1SJHCPU
QnACPU
•
Q2ACPU (-S1)
•
Q2ASCPU (-S1)
•
Q2ASHCPU (-S1)
•
Q3ACPU
•
Q4ACPU
•
Q4ARCPU
•
Q2ASCPU (-S1)
•
Q2ASHCPU (-S1)
QCPU
(A mode)
–
Q02CPU-A
Q02HCPU-A
Q06HCPU-A
*
1
Including PLC CPU with link function.
*
2
When using the A73CPU(-S3), mount the AD75M1, AD75M2 or AD75M3 on the
extension base unit.
Remote I/O station (MELSECNET/10, MELSECNET (II), MELSECNET/B)
The AD75M1/AD75M2/AD75M3 and A1SD75M1/A1SD75M2/A1SD75M3
positioning modules are applicable for the data link system (MELSECNET (II)/B) and
network system (MELSECNET/10) remote I/O station, with the exception of
A0J2P25/R25 (remote I/O station).
