APPENDIX
Appendix 1.1 Precautions for write during RUN of a dedicated instruction
REMARK
The detailed error code 104 means that "the configuration of the program using
dedicated CC-Link instructions is not correct." (Refer to Section 11.3.2)
Contents of Write during RUN For LEDA For LEDB
Write normal configuration during
RUN
After writing, the instruction is
executed with the previous
contact ON.
After writing, the instruction is
executed when the previous contact is
turned from OFF to ON.
LEDA/LEDB was added by
mistake.
Detailed error code, 104 is
reported.
If the previous contact remains ON
after writing, no execution causes no
processing and detailed error code
104 is reported when the previous
contact is turned from OFF to ON.
LEDA/LEDB was deleted by
mistake.
LEDC/SUB/LEDR is handled as a normal instruction.
LEDC/SUB was added by
mistake.
Detailed error code, 104 is
reported.
If the previous contact remains ON
after writing, no execution causes no
processing and detailed error code
104 is reported when the previous
contact is turned from OFF to ON.
LEDC/SUB was deleted by
mistake.
Detailed error code, 104 is
reported.
If the previous contact remains ON
after writing, no execution causes no
processing and detailed error code
104 is reported when the previous
contact is turned from OFF to ON.
LEDR was added by mistake.
LEDR in the back is handled as a
normal instruction.
LEDR in the back is handled as a
normal instruction.
LEDR was deleted by mistake.
If no LEDR exists immediately
after the deleted LEDR, detailed
error code 104 is reported.
If no LEDR exists immediately after
the deleted LEDR, detailed error code
104 is reported.
When the LEDR exists, all instructions
found between them are not executed.
