5 - 1
5. POWER SUPPLY MODULE
5 POWER SUPPLY MODULE
5.1 Specifications
Specifications of power supply modules are shown below.
Table 5.1 Power supply module specifications
Item
Performance Specifications
A1S61PN A1S62PN A1S63P
Slot position Power supply module slot
Input power supply
100 to 240VAC
(85 to 264VAC)
24VDC
(15.6 to 31.2VDC)
Input frequency
50/60Hz 5
–
Input voltage distortion Within 5% (See Section 8.8) –
Max. input apparent power 105VA 41W
Inrush current
20A, 8ms or less
*4
81A, 1ms or less
Rated output
current
5VDC 5A 3A 5A
24VDC – 0.6A –
Overcurrent
protection
*1
5VDC 5.5A or higher 3.3A or higher 5.5A or higher
24VDC – 0.66A or higher –
Overvoltage
protection
*2
5VDC 5.5 to 6.5V
24VDC –
Efficiency 65% or higher
Allowable momentary power
failure period
*3
20ms or less
10ms or less
(24VDC or higher)
Dielectric
withstand
voltage
Between primary
and 5VDC
AC across input/LG and output/FG,
2,830VAC rms/3 cycles (elevation 2,000m (6562 ft))
500VAC
Between primary
and 24VDC
–
Insulation resistance
AC across input/LG and output/FG 10M or higher, measures with a 500VDC
insulation resistance tester
Noise durability
• Noise voltage 1,500 Vp-p, Nioise width 1 s,
Noise frequency 25 to 60Hz (noise simulator condition)
• Noise voltage IEC801-4, 2kV
Noise voltage 500Vp-p,
Noise width 1 s, Noise
frequency 25 to 60 Hz
(noise simulator condition)
Operation indication LED indication (ON for 5VCDC output)
Fuse Built in (User cannot change.)
Terminal screw size M3.5 7
Applicable wire size
0.75 to 2mm
2
Applicable solderless terminal RAV1.25 to 3.5, RAV2 to 3.5
Applicable tightening torque
59 to 88N cm
+10%
-15%
+30%
-35%
