2 - 11
2. SYSTEM CONFIGURATION
2.3 System Equipment
The following shows the system equipment (modules and peripheral devices) that can be
used in an AnS system.
(1) AnS series modules
Product Name Model Name Description
Number of occupied points
(points)
[I/O Assignment
Module Type]
Current
Consumption
Remark
5VDC(A) 24VDC(A)
CPU module
A1SJHCPU
Number of I/O points: 256, memory capacity: 64k
bytes,
Number of I/O slots: 5
–0.30–
Built-in RAM
memory
A1SJHCPU
(S8)
Number of I/O points: 256, memory capacity: 64k
bytes,
Number of I/O slots: 8
–0.30–
A1SHCPU
Number of I/O points: 256, memory capacity: 64k
bytes,
–0.30–
A2SHCPU
Number of I/O points: 512, memory capacity: 256k
bytes
–0.40–
A2SHCPU-
S1
Number of I/O points: 1024, memory capacity: 192k
bytes
–0.40–
Power supply
module
A1S61PN 5VDC, 5A
100/200VAC
input
–––
Installed in the
power supply slot
of the main base
and extension
base.
A1S62PN 5VDC, 3A/24VDC, 0.6A
A1S63P 5VDC, 5A 24VDC input
To Next Page
