2 - 12

SYSTEM CONFIGURATION2.

Input module

A1SX10 16-point 100 to 120 VAC input module 16 [16 input points] 0.05 –

A1SX10EU 16-point 100 to 120VAC input module 16 [16 input points] 0.05 –

A1SX20 16-point 200 to 240VAC input module 16 [16 input points] 0.05 –

A1SX20EU 16-point 200 to 240VAC input module 16 [16 input points] 0.05 –

A1SX30 16-point 12/24VDC, 12/24VAC input module 16 [16 input points] 0.05 –

A1SX40 16-point 12/24VDC input module 16 [16 input points] 0.05 –

A1SX40-S1 16-point 24VDC input module 16 [16 input points] 0.05 –

A1SX40-S2 16-point 24VDC input module 16 [16 input points] 0.05 –

A1SX41 32-point 12/24VDC input module 32 [32 input points] 0.08 –

A1SX41-S1 32-point 24VDC input module 32 [32 input points] 0.12 –

A1SX41-S2 32-point 24VDC input module 32 [32 input points] 0.08 –

A1SX42 64-point 12/24VDC input module 64 [64 input points] 0.09 –

A1SX42-S1 64-point 24VDC input module 64 [64 input points] 0.16 –

A1SX42-S2 64-point 24VDC input module 64 [64 input points] 0.09 –

A1SX71 32-point 5/12/24VDC input module 32 [32 input points] 0.075 –

A1SX80 16-point 12/24VDC sink/source input module 16 [16 input points] 0.05 –

A1SX80-S1 16-point 24VDC sink/source input module 16 [16 input points] 0.05 –

A1SX80-S2 16-point 24VDC sink/source input module 16 [16 input points] 0.05 –

A1SX81 32-point 12/24VDC sink/source input module 16 [16 input points] 0.08 –

A1SX81-S2 32-point 24VDC sink/source input module 32 [32 input points] 0.08 –

A1SX82-S1 64-point 24VDC sink/source input module 32 [32 input points] 0.16 –

*1:0.08A is shown on the rating plate of the module.

Product Name Model Name Description

Number of occupied points

(points)

[I/O Assignment

Module Type]

Current

Consumption

Remark

5VDC(A) 24VDC(A)

Mitsubishi A2SHCPU (S1) User Manual
