SYSTEM CONFIGURATION2.
Output module
A1SY10 16-point relay contact output module (2A) 16 [16 output points] 0.12 0.09
A1SY10EU 16-point relay contact output module (2A) 16 [16 output points] 0.12 0.10
A1SY14EU 12-point relay contact output module (2A) 16 [16 output points] 0.12 0.10
A1SY18A
8-point relay contact output module (2A) for
independent contacts
16 [16 output points] 0.24 0.075
A1SY18AEU
8-point relay contact output module (2A) for
independent contacts
16 [16 output points] 0.24 0.075
A1SY22 16-point triac output module (0.6A) 16 [16 output points] 0.27
(200VAC)
0.002
A1SY28A
8-point triac output module (1A)
All points independent
16 [16 output points] 0.13 –
A1SY40
16-point 12/24VDC transistor output module
(0.1A) sink type
16 [16 output points] 0.27 0.008
A1SY40P
16-point 12/24VDC transistor output module (0.1A)
sink type
16 [16 output points]
0.079
*2
0.011
A1SY41
32-point 12/24VDC transistor output module
(0.1A) sink type
32 [32 output points] 0.50 0.008
A1SY41P
32-point 12/24VDC transistor output module (0.1A)
sink type
32 [32 output points]
0.141
*3
0.012
A1SY42
64-point 12/24VDC transistor output module
(0.1A) sink type
64 [64 output points] 0.93 0.008
A1SY50
16-point 12/24VDC transistor output module
(0.5A) sink type
16 [16 output points] 0.12 0.06
A1SY60
16-point 24VDC transistor output module
(2A) sink type
16 [16 output points] 0.12 0.015
A1SY60E
16-point 12/24VDC transistor output module
(2A) source type
16 [16 output points] 0.20 0.01
A1SY68A
8-point 5/12/24/48VDC
transistor output module (2A) sink/source type
All points independent
16 [16 output points] 0.11 –
A1SY71
32-point 5/12VDC transistor output module
(0.016A) sink type
32 [32 output points] 0.40 0.15
A1SY80
16-point 12/24VDC transistor output module
(0.8A) source type
16 [16 output points] 0.12 0.02
A1SY81
32-point 12/24VDC transistor output module
(0.1A) source type
32 [32 output points] 0.50 0.008
A1SY82
64-point 12/24VDC transistor output module
(0.1A) source type
64 [64 output points] 0.93 0.008
*2:0.08A is shown on the rating plate of the module.
*3:0.15A is shown on the rating plate of the module.
Product Name Model Name Description
Number of occupied points
(points)
[I/O Assignment
Module Type]
Current
Consumption
Remark
5VDC(A) 24VDC(A)
