SYSTEM CONFIGURATION2.
I/O hybrid
module
A1SH42
32-point 12/24VDC input module
32-point 12/24VDC transistor output module
(0.1A) sink type
32 [32 output points] 0.50 0.008
A1SH42P
32-point 12/24VDC input module
32-point 12/24VDC transistor output module
(0.1A) sink type
32 [32 output points] 0.13 0.012
A1SH42-S1
32-point 24VDC input module
32-point 12/24VDC transistor output module
(0.1A) sink type
32 [32 output points] 0.50 0.008
A1SH42P-S1
32-point 24VDC input module
32-point 12/24VDC transistor output module
(0.1A) sink type
32 [32 output points] 0.13 0.012
A1SX48Y18
8-point 24VDC input module
8-point relay contact output module (2A)
16 [16 output points]
0.085
*4
0.045
A1SX48Y58
8-point 24VDC input module
8-point 12/24VDC transistor output module (0.5A)
16 [16 output points] 0.06 0.06
Dynamic input
module
A1S42X
16/32/48/64 points
12/24VDC dynamic input module
Specified number of points
[Input
]
0.08 –
Dynamic output
module
A1S42Y
16/32/48/64 points
12/24VDC dynamic output module
Specified number of points
[Output
]
0.18 0.055
*4:0.09A is shown on the rating plate of the module.
Product Name Model Name Description
Number of occupied points
(points)
[I/O Assignment
Module Type]
Current
Consumption
Remark
5VDC(A) 24VDC(A)
Specified number of points
Specified number of points
