5 - 2
POWER SUPPLY MODULE5.
External dimensions 130mm(5.12inch) 55mm(2.17inch) 93.6mm(3.69inch)
Weight 0.60kg 0.60kg 0.50kg
Table5.2 Performance specifications for the A1SJHCPU(S8) built -in power supply
Item
Model
A1SJHCPU(S8)
Input power supply
100 to 120VAC
(85 to 132VAC)
200 to 240VAC
(170 to 264VAC)
Input frequency
50/60Hz 3Hz
Input voltage distortion Within 5% (See Section 8.8)
Max. input apparent power 100VA
Inrush current
20A, 8ms or less
*4
Rated output 5VDC, 3A
Overcurrent protection
*1
3.3A or higher
Overvoltage protection
*2
None
Efficiency 65% or higher
Power indicator POWER LED indicator
Terminal screw size M3.5 8
Applicable wire size
0.3 to 2mm
2
Applicable solderless terminal RAV1.25 to 3.5, RAV2 to 3.5
Allowable momentary power failure period
*3
20ms or less (100VAC or more)
Dielectric
withstand
voltage
Between primary and 5VDC
AC across input/LG and output/FG,
2,830VAC rms/3 cycles (elevation 2,000m (6562 ft))
Between primary and 24VDC
Insulation resistance
AC across input/LG and output/FG 10M or higher, measures with a
500VDC insulation resistance tester
Noise durability
• Noise voltage 1,500 Vp-p, Nioise width 1 s,
Noise frequency 25 to 60Hz (noise simulator condition)
• Noise voltage IEC801-4, 2kV
Item
Performance Specifications
A1S61PN A1S62PN A1S63P
+10%
-15%
+10%
-15%
