Mitsubishi A2SHCPU (S1) User Manual

2 - 7
SYSTEM CONFIGURATION2.
(3) Peripheral device
(a) Precautions when using an A6WU P-ROM writer
1) When using an A1SHCPU
Use an A6WU P-ROM writer module whose software version is E or later.
(b) The A6WU P-ROM writer module cannot be installed with add-on system, which
is installed directly in the AnSHCPU.
Only hand-held system, which is installed using cables, is possible.
(c) Among the programming modules (A7PUS and A8PUE), only the A7PUS can be
installed with add-on system.
Other models (A8PUE) can be installed with hand-held system, which is
connected with cables.
POINT
When the dedicated instruction for
the CC-Link is used, use the master
module marked "9707 B" or later in
the DATE column of the rated plate.
9707 B
DATE
MAX 30kSTEP
MITSUBISHI
CPU UNIT
MODEL
A2USHCPU-S1
MITSUBISHI ELECTRIC
BD992D008H38
Date of manufacture
Function version
