4 - 2
CPU MODULE4.
Performance specifications (Continued)
Item
Model
Remark
A1SJHCPU(S8) A1SHCPU A2SHCPU(S1)
Device points
Internal relay [M] 1000 points (M0 to M999)
Total 2048 shared by
M, L, S
The range can be
changed by
parameters.
Latch relay [L] 1048 points (L1000 to L2047)
Step relay [S] 0 point (None for the initial status)
Link relay [B] 1024 points (B0 to B3FF)
Timer [T]
256 points
•100ms timer (T0 to T199) ....................... Setting time: 0.1 to 3276.7s
•10ms timer (T200 to T255) .................... Setting time: 0.01 to 327.67s
•100ms retentive timer (none for initial) .... Setting time: 0.1 to 3276.7s
The range and number
of points for use set by
parameters
(Refer to Section
4.2.1.)
Counter [C]
256 points
•Normal counter (C0 to C255)............ Setting range: 1 to 32767 times
•Interrupt counter (none for default)... Can be use by setting the parameters.
The range and number
of points for use set by
parameters
(Refer to Section
4.2.1.)
Data register [D] 1024 points (D0 to D1023)
Link register [W] 1024 points (W0 to W3FF)
Annunciator [F] 256 points (F0 to F255) Fault finding device
File register [R] 8192 points (R0 to R8191)
Points set by
parameters
Accumulator [A] 2 points (A0, A1)
Index register [V, Z] 2 points (V, Z)
Pointer [P] 256 points (P0 to P255)
Interrupt pointer [I] 32 points (I0 to I31)
Special relay [M] 256 points (M9000 to M9255)
Special register [D] 256 points (D9000 to D9255)
