4 - 16
CPU MODULE4.
List of parameter setting range (Continued)
Item Default Value
Setting Range
A1SJHCPU(S8) A1SHCPU A2SHCPU(S1)
Watchdog timer setting 200ms 10ms to 2000ms (in units of 10ms)
Timer
settings
T0 to T255
T0 to T199
(100ms)
T200 to
T255(10ms)
• 256 points by 100ms, 10ms, and retentive timers (in 8-point units)
• Timers are serial numbers.
System
interrupt
setting
Interrupt counter
start No.
– • Sets the interrupt counter start Nos. (in units of 8 points).
I/O number assignment –
0 to 64 points (in 16-point units) .....................................
• Module model name registration is possible.
Remote RUN/PAUSE contact
setting
–
• X0 to X7FF
• RUN/PAUSE .......... 1 point (Setting only PAUSE contact is not allowed.)
Operating
mode when
there is an
error
Fuse blown Continue
Stop/Continue
I/O verify error Stop
Operation error Continue
Special function
module check
error
Stop
Data communication request
batch processing
None Yes/No
Output mode at STOP to RUN
Ouput data at
the time of
STOP restored
Output before STOP/after operation
Print title entry – • 128 characters
Keyword registration – • Up to 6 characters in hexadecimal (0 to 9, A to F)
Link range
settings for
MELSECNET
Number of link
stations
–
• 0 to 64 station(s)
I/O (X/Y)
X/Y0 to X/YFF
(in 16-point units)
X/Y0 to X/YFF
(in 16-point units)
X/Y0 to X/Y1FF
(in 16-point units)
Link relay (B) • B0 to B3FF (in units of 16 points)
Link register (W) • W0 to W3FF (in units of 1 point)
Input module/output module
Special function module/empty slot
