Mitsubishi A2SHCPU (S1) User Manual

4 - 23
CPU MODULE4.
No. Name Description
(1)
RUN STOP
key switch
• RUN/STOP: Used to start/stop sequence program operation.
• RESET: Resets the hardware.
Performs the reset and initialization of the operation at the operation
error occurrence.
•L.CLR
(LATCH CLEAR):
Clears the data in the latch area (to OFF or 0) set by
parameters.
(With LATCH CLEAR, data in area other than the latch
area is also cleared.)
For the operation method of the latch clear, refer to
Section 4.5.3.
