4 - 25
CPU MODULE4.
(13) Power input terminal
Used to connect the 100VAC or 200VAC power supply using the power input
terminal.
(14) LG terminal Power filter grounding terminal, having the potential half of the input voltage.
(15) FG terminal
The ground terminal connected to the shielding pattern of the printed-circuit
board.
(16) DIN rail Hook for DIN rail installation. (2pcs)
(17) RS-422 connector cover Connector cover for the RS-422
(18) Module connector
Connector to install a I/O module or a special module.
To prevent dust from entering, attach the supplied connector cover or a blank
cover (A1SG60) to the connector with no module installed. Number of I/O slots
A1SJHCPU:5
A1SJHCPU-S8:8
(19) Extension cable connector
A connector used to connect an extension cable, by which signals can be
transferred to/from an extension base unit.
(20) Base cover
Protective cover for extension connector.
To extend, the area surrounded by the groove below the OUT sign on the base
cover has to be removed using a tool such as a nipper.
(21) Module fixing screw
A screw to fix the module to the base. (M4 12 screws)
(22) Hardware version Hardware version seal of CPU module
(23) Software version Software version seal of CPU module
No. Name Description
