6 - 4
BASE UNIT AND EXTENSION CABLE6.
(3) Receiving voltage calculation method
(a) Calculation of voltage drops with the main base unit (A1S32B, A1S33B,
A1S35B, A1S38B) Resistive value with the main base unit is 0.007 per
slot.Sum up the voltage drops of each slot.
Current consumption of the CPU module
1) Voltage drop at the CPU module: V
CPU
2) Voltage drop at slot 0: V0
3) Voltage drop at slot 1: V1
4) Voltage drop at slot 2: V2
5) Voltage drop at slot 3: V3
6) Voltage drop at slot 4: V4
7) Voltage drop at slot 5: V5
8) Voltage drop at slot 6: V6
9) Voltage drop at slot 7: V7
10) Total voltage drop at the main base unit: VK
VCPU, V0 to V7:Voltage drop at each slot of the main base unit
I
CPU, I0 to I7 :Current consumption at each slot of the main base unit
V
8 to V15 :Voltage drop at each slot of the extension base unit
I
8 to I15 :Current consumption at each slot of the extension base unit
A1SJHCPU(S8), A1SHCPU :0.3(A)
A2SHCPU(S1) :0.4(A)
V
CPU=0.007(ICPU + I0 + I1 + I2 + I3 + I4 + I5 + I6 + I7 + I8 + I9
+ I10 + I11 + I12 + I13 + I14 + I15)
V
0=0.007(I0 + I1 + I2 + I3 + I4 + I5 + I6 + I7 + I8 + I9 + I10
+ I11 + I12 + I13 + I14 + I15)
V
1=0.007(I1 + I2 + I3 + I4 + I5 + I6 + I7 + I8 + I9 + I10 + I11
+ I12 + I13 + I14 + I15)
V
2=0.007(I2 + I3 + I4 + I5 + I6 + I7 + I8 + I9 + I10 + I11 + I12
+ I13 + I14 + I15
V3=0.007(I3 + I4 + I5 + I6 + I7 + I8 + I9 + I10 + I11 + I12 + I13
+ I14 + I15)
V
4=0.007(I4 + I5 + I6 + I7 + I8 + I9 + I10 + I11 + I12 + I13
+ I14 + I15)
V
5=0.007(I5 + I6 + I7 + I8 + I9 + I10 + I11 + I12 + I13 + I14
+ I15)
V
6=0.007(I6 + I7 + I8 + I9 + I10 + I11 + I12 + I13 + I14 + I15)
V
7=0.007(I7 + I8 + I9 + I10 + I11 + I12 + I13 + I14 + I15)
V
K=VCPU + V0 + V1 + V2 + V3 + V4 + V5 + V6 + V7
02
1 34567 8910
11 12
13 14 15
CPU module
V
CPU
ICPU
V0
V1 V2 V3 V4 V5
V6
V7
V8
V9 V10 V11 V12 V13
V14
V15
I8
I9 I10 I11 I12 I13
I14
I15
I0
I1 I2 I3 I4 I5 I6 I7
To Next Page
