Mitsubishi D700 VFD - Setting Spindle Speed in Mach3

15 | P a g e
Turning on Your Spindle
To turn on your spindle, begin by setting up your spindle speed. Navigate to Prog Run and click on the Spindle S:
user input. Enter your speed and press Send as shown in Figure 8.
Figure 8 Setting up Spindle Speed
Note: If you don’t have the MachMotion screen set, spindle speed can be changed right on the main screen of the
Mill profile. Click on the user input, enter a new number, and then press enter.
Figure 9 Spindle Speed in RPM
Set Spindle
Speed Here
Spindle Speed
Press Send
