3-42
Features and controls
3
Selector lever position indicator/ “N” indicator
N00513900239
Automatic transaxle fluid temperature warning
light
N00514000110
The automatic transaxle fluid temperature warning light comes
on when the automatic transaxle fluid temperature becomes
abnormally high. Normally the warning light comes on when
the ignition key is turned to the “ON” position, and then will go
out after a few seconds.
A- Selector lever position indicator
When the ignition key is turned to the “ON” position, the
indicator in the instrument cluster comes on to show the
position of the selector lever (i.e. “PARK”, “DRIVE”,
“REVERSE”, etc.).
B- “N” indicator
If the “N” indicator blinks with the “D” (DRIVE) position or
“Sports mode” being selected, the automatic transaxle may
be malfunctioning.
Have your vehicle inspected by an authorized Mitsubishi
Motors dealer or a repair facility of your choice as soon as
possible.
