F9Q ENGINE
–
Camshaft
and V
acuum Pump
1
1A-10-3
INSPECTION
CAMSHAFT
Measure
the end
play
. Replace the camshaft if the
measurement
does not meet the standard value.
Standard value: 0.05
–
0.13 mm
PWEE0001
E
Jun. 2000
Mitsubishi Motors Corporation
PWEE0001-A
E
Mar
. 2001
Mitsubishi Motors Corporation
Added
REN0184
28
30
