1.3 Structure
OUTLINE
3
1.3 Structure
1.3.1 Appearance and structure
(1) Front view
POWER lamp
ALARM lamp
Operation panel (FR-DU04)
Accessory cover
Wiring port cover for option
Front cover
Rating plate
Capacity plate
(2) Without front cover
Wiring cover
PU connector
(Provided with modular jack type relay connector)
(For use with RS-485 cable communication)
Modular jack type relay connector compartment
Inboard option mounting positions
Control circuit terminal block
Main circuit terminal block
Note: The "EC" version of the FR-F500 uses pheonix type connectors for the control circuit terminal block.
