4.2.54 Advanced PID control (Pr. 500 to Pr. 516) (NA, EC versions only)
Pr. 500 "Auxiliary motor operation selection"
Pr. 501 "Motor switch-over selection"
Pr. 502 "MC switching interlock time"
Pr. 503 "Start waiting time"
Pr. 504 "Auxiliary motor connection-time deceleration time"
Pr. 505 "Auxiliary motor disconnection-time acceleration time"
Pr. 506 "Output stop detection time"
Pr. 507 "Output stop detection level"
Pr. 508 "Output stop cancel process value level"
Pr. 509 "Auxiliary motor 1 starting frequency"
Pr. 510 "Auxiliary motor 2 starting frequency"
Pr. 511 "Auxiliary motor 3 starting frequency"
Pr. 512 "Auxiliary motor 1 stopping frequency"
Pr. 513 "Auxiliary motor 2 stopping frequency"
Pr. 514 "Auxiliary motor 3 stopping frequency"
Pr. 515 "Auxiliary motor start delay frequency"
Pr. 516 "Auxiliary motor stop delay frequency"
With the advanced PID control functions, you can control pumps/fans using several motors (maximum of 4
motors).
<Operation outline>
#
Set the number of commercial power supply operation motors in Pr. 500 "auxiliary motor operation
selection", and the motor switch-over method in Pr. 501 "motor switch-over selection".
Pr. Number Name Setting Range Setting Increments Factory Setting Description
500
Auxiliary motor
operation selection
0 to 3 1 0
Set the number of auxiliary
motors to be run. (1 to 3
motors)
0: Auxiliary motors are not run.
501
Motor switch-over
selection
0 to 2 1 0
0: Basic Method
1: Alternative Method
2: Direct Method
Pr. 128 to Pr.134 (PID control)
Pr. 180 to Pr. 186
(input terminal assignment)
Pr. 190 to Pr. 195
(output terminal assignment)
Related parameters
