3.2.3 Monitoring
•
Operation command indications in the monitoring
EXT is lit to indicate external operation.
PU is lit to indicate PU operation.
Both EXT and PU are lit to indicate PU/external combined operation mode.
•
The monitor display can also be changed during operation.
MODE
SET
SET
SET
SET
SET
SET
*1
SET
*1
SET
*1
*2
To 3.2.4 Frequency setting (Note 3)
#
Frequency monitor
#
Current monitor
#
Voltage monitor
#
Alarm monitor
Alarm
present
Alarm absent
FR-DU04
CONTROL PANEL
Hz
MON EXT PU
A
V
REV FWD
FR-DU04
CONTROL PANEL
Hz
MON EXT PU
A
V
REV FWD
FR-DU04
CONTROL PANEL
Hz
MON EXT PU
A
V
REV FWD
FR-DU04
CONTROL PANEL
Hz
MON EXT PU
A
V
REV FWD
Note: 1. Hold down the
SET
key marked *1 for more than 1.5 seconds to change the current monitor to the
power-on monitor.
2. Hold down the
SET
key marked *2 for more than 1.5 seconds to display four errors including the
most recent one.
3. Shifts to the parameter setting mode when in the external operation mode.
3.2.4 Frequency setting
•
Used to set the running frequency in the PU operation mode.
MODE
SET
MODE
To 3.2.5 Parameter setting method
#
Set frequency write
#
Set frequency change
Press to change the set frequency.
To frequency monitor
FR-DU04
CONTROL PANEL
Hz
MON EXT PU
A
V
REV FWD
FR-DU04
CONTROL PANEL
Hz
MON EXT PU
A
V
REV FWD
FR-DU04
CONTROL PANEL
Hz
MON EXT PU
A
V
REV FWD
FR-DU04
CONTROL PANEL
Hz
MON EXT PU
A
V
REV FWD
Flicker
#
Frequency setting mode
