Mitsubishi FUEL User Manual

MPI <6A1> -
Troubleshooting
13A-180
Item
No.
Reference
page
Inspection
procedure
No.
Normal conditionInspection contentsInspection
item
41
Injectors*
3
Engine: Cranking When engine
coolant temperature
is 0
_
C (injection is
carried out for all
cylinders simulta-
neously)
23 - 80 ms - -
When engine
coolant temperature
is 20
_
C
12 - 40 ms
When engine
coolant temperature
is 80
_
C
2.0 - 8.0 ms
Injectors*
4
D
Engine coolant
temperature:
80 – 95
_
C
Engine is idling 2.6 - 3.8 ms
80 – 95
_
C
D
Lamps, electric
cooling fan and
all accessories:
2,500 r/min 1.8 - 3.0 ms
OFF
D
Transmission:
Neutral
(A/T: P range)
When engine is
suddenly raced
Increases
44 Ignition
coils and
power
transistors
D
Engine: After
having warmed
up
D
Timing lamp is
Engine is idling 1-15
_
BTDC - -
set. (The timing
lamp is set in
order to check
actual ignition
timing.)
2,500 r/min 23 - 43
_
BTDC
45 ISC (step-
per) motor
position*
5
D
Engine coolant
temperature:
80 - 95
_
C
D
Lamps, electric
A/C switch: OFF 2 - 25 STEP - -
cooling fan and
all accessories:
OFF
D
Transmission:
Neutral
(A/T: P range)
A/C switch:
OFF ® ON
Increases by 10 -
70 steps
(A/T: P range)
D
Idle position
switch: ON
D
Engine: Idling
D
When A/C switch
is ON, A/C
compressor
should be
operating
D
A/C switch:
OFF
D
Select lever:
N range ® D
range
Increases by 5 -
50 steps
