MPI <6A1> -
Troubleshooting
13A-183
ACTUATOR TEST REFERENCE TABLE
Item
No.
Inspection
item
Drive contents Inspection contents Normal condition Inspection
procedure
No.
Reference
page
01 Injectors Cut fuel to No.
1 injector
Engine:
After having warmed up/
Idling condition
becomes different
Code No.
P0201,
13A-127
02 Cut fuel to No.
2 injector
Engine is idling
(Cut the fuel supply to each
injector in turn and check
(becomes unsta-
ble).
P0202,
P0203,
P0204,
03 Cut fuel to No.
3 injector
cylinders which don’t affect
idling.)
P0205,
P0206
04 Cut fuel to No.
4 injector
05 Cut fuel to No.
5 injector
06 Cut fuel to No.
6 injector
07 Fuel pump Fuel pump
operates and
fuel is recircu-
lated.
D
Engine:
Cranking
D
Fuel
pump:
Forced
driving
Inspect
Pinch the
return hose
with fingers
to feel the
pulse of the
fuel being
recirculated.
Pulse is felt. Procedure
No. 28
13A-172
according
to both
the above
conditions.
Listen near
the fuel tank
for the
sound of
fuel pump
operation.
Sound of opera-
tion is heard.
08 Purge con-
trol sole-
noid valve
Solenoid valve
turns from OFF
to ON.
Ignition switch: ON Sound of opera-
tion can be heard
when solenoid
valve is driven.
Code No.
P0443
13A-136
10 EGR con-
trol sole-
noid valve
Solenoid valve
turns from OFF
to ON.
Ignition switch: ON Sound of opera-
tion can be heard
when solenoid
valve is driven.
Code No.
P0403
13A-133
15 Vacuum
control
solenoid
valve
<Vehicles
with TCL>
Solenoid valve
turns from OFF
to ON.
Ignition switch: ON Sound of opera-
tion can be heard
when solenoid
valve is driven.
Code No.
P1101
13A-141
16 Ventilation
control
solenoid
valve
<Vehicles
with TCL>
Solenoid valve
turns from OFF
to ON.
Ignition switch: ON Sound of opera-
tion can be heard
when solenoid
valve is driven.
Code No.
P1102
13A-142
