MPI <4G6> -
Troubleshooting
13A-85
Terminal
No. <M/T>
Normal conditionCheck condition (Engine condition)Check itemTerminal
No. <A/T>
84 78 Throttle
position
Ignition switch:
ON
Set throttle valve
to idle position
0.3 - 1.0 V
sensor
Fully open throttle
valve
4.5 - 5.5 V
85 55 Barometric
pressure
Ignition switch:
ON
When altitude is 0
m
3.7 - 4.3 V
sensor
When altitude is
1,200 m
3.2 - 3.8 V
86 80 Vehicle
speed sensor
D
Ignition switch: ON
D
Move the vehicle slowly forward
0 « 5V
(Changes repeatedly)
87 79 Idle position
switch
Ignition switch:
ON
Set throttle valve
to idle position
0-1V
Slightly open
throttle valve
4 V or more
88 56 Camshaft Engine: Cranking 0.4 - 3.0 V
position
sensor
Engine: Idle speed 0.5 - 2.0 V
89 45 Crank angle Engine: Cranking 0.4 - 4.0 V
sensor
Engine: Idle speed 1.5 - 2.5 V
90 65 Air flow sen- Engine: Idle speed 2.2 - 3.2 V
sor
Engine r/min: 2,500 r/min
CHECK CHART FOR RESISTANCE AND CONTINUITY
BETWEEN TERMINALS
1. Turn the ignition switch to “LOCK” (OFF) position.
2. Disconnect the engine-ECU <M/T> or engine-A/T-ECU
<A/T> connector.
3. Measure the resistance and check for continuity between
the terminals of the engine-ECU <M/T> or
engine-A/T-ECU <A/T> harness-side connector while
referring to the check chart.
NOTE
(1) When measuring resistance and checking continuity,
a harness for checking contact pin pressure should
be used instead of inserting a test probe.
(2) Checking need not be carried out in the order given
in the chart.
