FX 3G /FX 3U /FX 3UC PLC User's Manual - Positioning Control Edition
Built-in Positioning Functions
8 1-Speed Positioning - DRVI/DRVA Instruction
8.2 Drive to Increment - DRVI Instruction
B - 113
A
Common Items
B
Built-in Positioning Functions
Apx.
Example Connection
2. Special data registers
The following table shows the related special data registers. Note that Y000, Y001, Y002, and Y003 are
devices that determine the pulse output destinations.
*1. Y002 is not available in 14-point and 24-point type FX3G PLC.
*2. Devices related to Y003 (pulse output destination) are only valid if two FX
3U-2HSY-ADP adapters are
connected to the FX
3U PLC.
Device number
Function
Data
length
Initial
value
Refer to
Y000 Y001
Y002
*1
Y003
*2
D8340
Low-
order
D8350
Low-
order
D8360
Low-
order
D8370
Low-
order
Current value register
(PLS)
32-bit 0
Subsection
4.4.1
D8341
High-
order
D8351
High-
order
D8361
High-
order
D8371
High-
order
D8342 D8352 D8362 D8372 Bias speed (Hz) 16-bit 0
Subsection
4.2.6
D8343
Low-
order
D8353
Low-
order
D8363
Low-
order
D8373
Low-
order
Maximum speed (Hz) 32-bit 100,000
Subsection
4.2.5
D8344
High-
order
D8354
High-
order
D8364
High-
order
D8374
High-
order
D8345 D8355 D8365 D8375 Creep speed (Hz) 16-bit 1000
Subsection
4.2.4
D8346
Low-
order
D8356
Low-
order
D8366
Low-
order
D8376
Low-
order
Zero return speed (Hz) 32-bit 50,000
Subsection
4.2.3
D8347
High-
order
D8357
High-
order
D8367
High-
order
D8377
High-
order
D8348 D8358 D8368 D8378 Acceleration time (ms) 16-bit 100
Subsection
4.2.7
D8349 D8359 D8369 D8379 Deceleration time (ms) 16-bit 100
Subsection
4.2.8
