Club cab
Item
Easy select 4WD
Super select 4WD
LHD RHD
Kerb weight
Without optional parts
1,800 kg 1,800 kg
1,815 kg, 1,825 kg
*1
With full optional parts
1,900 kg 1,880 kg
1,910 kg, 1,920 kg
*1
Maximum gross vehicle weight 2,850 kg
Maximum axle weight Front 1,260 kg
Rear 1,800 kg
Maximum towable weight With brake 2,700 kg
Without brake 750 kg
Maximum trailer-nose weight 115 kg
Maximum gross combination weight 5,500 kg
Maximum permissible weight of the coupling device
45 kg
*2
Seating capacity (including a driver) 4 persons
*1
: Vehicles with high power engine
*2
: Crossmember (weight = 10 kg) must be dismounted
NOTE
l
Trailer specifications indicate the manufacturer’s recommendation.
l
When loading luggage and/or towing a trailer, make sure not to exceed any of the above maximum weights all the time.
Specifications
9-11
9
