２ Robot arm
Names of each part of the robot 2-16
2.3 Names of each part of the robot
Fig.2-2 ： Names of each part of the robot
＋
－
＋
－
＋
－
＋
－
＋
－
＋
－
Note1)
J5 axis
J6 axis
Fore arm
Mechanical interface
(Hand installation flange surface)
Upper arm
J1 axis
J3 axis
J4 axis
Base
Elbow block
Shoulder
J2 axis
Elbow
Note1)J4-axis dosen't exist for 5-axis type.
* This part doesn't exist
for the 5-axis type.
Wrist
Waist
