2-39 Maintenance parts
２ Robot arm
Table 2-28 ： Consumable part (packing) list
No.
part name
Details of configuration Usage place
Packing name Qty. Cover name Qty. Sticking side
RV-3SQ series ﾞ
1 Cover packing A set
Part Code ： K07S24021557
Conbox packing L 1
CONBOX cover
1Cover side
Conbox packing R 1 1 Cover side
Shoulder A packing 1 Shoulder cover A 1 Cover side
Shoulder B packing T 1
Shoulder cover B
1Cover side
Shoulder B packing B 1 1 Cover side
Elbow B packing 1 Elbow cover B 1 Cover side
ADD packing 1 ADD cover 1 Cover side
2 Cover packing B set
Part Code ： K07S24021558
Elbow A packing L 1
Elbow cover A
1Cover side
Elbow A packing R 1 1 Cover side
Elbow C packing 1 Elbow cover C 1 Cover side
Elbow D packing T 1
Elbow cover D
1Cover side
Elbow D packing B 1 1 Cover side
3PackingA
Part Code ： K07S24409801
PackingA
1
No.1 arm cover 1 Robot arm side
Bottom plate 2 Robot arm side
4 No.2 arm cover packing
Part Code ： K07S24342001
No.2 arm cover packing
1 No. 2 arm cover A 1 Cover side
5 No.2 arm cover C packing
Part Code ： K07S24401502
No.2 arm cover C packing
1 No. 2 arm cover C 1 Robot arm side
6 Wrist cover packing
Part Code ： K07S24401602
Wrist cover packing
1 Wrist cover 1 Robot arm side
RV-3SQJ/3SQJC
7 Cover packing A set
Part Code ： K07S24021557
Conbox packing L 1
CONBOX cover
1Cover side
Conbox packing R 1 1 Cover side
Shoulder A packing 1 Shoulder cover A 1 Cover side
Shoulder B packing T 1
Shoulder cover B
1Cover side
Shoulder B packing B 1 1 Cover side
Elbow B packing 1 Elbow cover B 1 Cover side
ADD packing 1 ADD cover 1 Cover side
8 Elbow E packing
Part Code ： K07S24338651
Elbow E packing F 1
Elbow cover B
1Cover side
Elbow E packing B 1 1 Cover side
9PackingA
Part Code ： K07S24409801
PackingA
1
No.1 arm cover 1 Robot arm side
Bottom plate 2 Robot arm side
10 No.2 arm cover packing
Part Code ： K07S24342001
No.2 arm cover packing
1 No. 2 arm cover A 1 Cover side
11 No.2 arm cover C packing
Part Code ： K07S24401502
No.2 arm cover C packing
1 No. 2 arm cover C 1 Robot arm side
12 Wrist cover packing
Part Code ： K07S24401602
Wrist cover packing
1 Wrist cover 1 Robot arm side
To Next Page
