Mitsubishi MELFA SQ Series User Manual

3 Controller
Names of each part 3-46
Fig.3-3 ： operation lock of the power switch(DU2A-700)
Lock cover
Lock plate
Padlock (prepare by customer)
Dimension of the padlock
Dimension (mm)
ABC
25 14 4mm or less
The lock device which can be used
＜ DU2A-700 ＞
Handle
Do not operate the trip test by the trip
button in the state of the power switch
locked at OFF position.
The Lock plate is installed strongly.
Pull up strongly and remove.
CAUTION
