3 Controller
Magnet contactor control connector output (AXMC) for addition axes 3-76
Fig.3-29 ： EMGOUT connector （DU1A-700）
EMGOUT connector
EMGOUT2
EMGOUT1
6A
5A
4A
3A
2A
1A
6B
5B
4B
3B
2B
1B
Type ：1-1871940-6
Minus driver plug area
AWG#24～#18
(0.2～
0
.75mm
2
)
Electric wire plug area
Internal circuit
EMGOUT1
EMGOUT2
（Custmer）
（Controller）
6A
5A
6B
5B
EMGOUT
Contactor control output
for addition axes
(AXMC1)
Contactor control output
for addition axes
(AXMC1)
<DU1A-700>
* The figure is Standard specification.
(The CE marking specification is the same.)
