3-77 Magnet contactor control connector output (AXMC) for addition axes
3 Controller
Fig.3-30 ： EMGOUT connector （DU2A-700）
EMGOUT
EMGOUT connector
EMGOUT2
EMGOUT1
6A
5A
4A
3A
2A
1A
6B
5B
4B
3B
2B
1B
Type ：1-1871940-6
Minus driver plug area
AWG#24～#18
(0.2～
0
.75mm
2
)
Electric wire plug area
Internal circuit
EMGOUT1
EMGOUT2
（Custmer）
（Controller）
6A
5A
6B
5B
Contactor control output
for addition axes
(AXMC1)
Contactor control output
for addition axes
(AXMC1)
<DU2A-700>
