List of parameter setting range (From the previous page)
Item Default value
Setting range
A2USHCPU-S1
A2ASCPU-S30
A2USCPU
A2ASCPU
A2USCPU-S1
A2ASCPU-S30
Link range
settings for
MELSECNET II
Number of link
stations
–
0 to 64 station(s)
I/O (X/Y)
X/Y0 to X/Y3FF
(in 16 point units)
X/Y0 to X/Y1FF
(in 16 point units)
X/Y0 to X/Y3FF
(in 16 point units)
Link relay (B)
B0 to BFFF (in 16 point units)
Link register (W)
W0 to WFFF (in 1 point units)
MELSECNET/
MINI,
MELSECNET/
MINI-S3
Latch range
setting
Number of
supported
modules
–
0 to 8 module(s)
Head I/O
number
0 to 1FF0 (in 10
H units)
Model name
registration
MINI, MINI-S3
Transmission/
reception data
X, M, L, B, T, C, D, W, R, none (16 point units for bit devices)
Number of
retries
0 to 32 times
FROM/TO
response
setting
Link priority; CPU priority
Faulty station
data
Retain/ Clear
Faulty station
detection
M, L, B, T, C, D, W, R, none (16 point units for bit devices)
Error No. T, C, D, W, R
Number of total
remote stations
0 to 64 stations
Sending state
setting during
communication
error
Test message, OFF data, retention (sending data)
