2 - 24
SYSTEM CONFIGURATION2.
Product Name Model Name Description Applicable model
Memory
cassette
E
2
PROM
A2SNMCA-30KE
With 30k-step E
2
PROM (direct connection)
Direct writing to and reading from a peripheral device is
feasible.
Battery A6BAT IC-RAM memory backup
Installed in the A2USHCPU-S1, A2USCPU(S1),
A2ASCPU(S1/S30) main unit
Connector/terminal
block converter unit
A6TBXY36
For the sink-type input module and sink-type output
module (standard type)
A1SX41(S1/S2), A1SX42(S1/S2), A1SY41, A1SY41P,
A1SY42, A1SY82, A1SH42(S1)
A6TBXY54
For the sink-type input module and sink-type output
module (2-wire type)
A6TBX70 For the sink-type input module (3-wire type) A1SX41(S1/S2),A1SX42(S1/S2),A1SH42(S1)
A6TBX36-E For the source-type input module (standard type) A1SX71, A1SX82-S1, A1SX81(S2)
A6TBY36-E For the source-type output module (standard type) A1SY81, A1SY82
A6TBX54-E For the source-type input module (2-wire type) A1SX71, A1SX82-S1, A1SX81(S2)
A6TBY54-E For the source-type output module (2-wire type) A1SY81, A1SY82
A6TBX70-E For the source-type input module (3-wire type) A1SX71, A1SX82-S1, A1SX81(S2)
Cable for connector/
terminal block
converter unit
AC05TB 0.5m (1.64ft.) for the source module
A6TBXY36
A6TBXY54
A6TBX70
AC10TB 1m (3.28ft.) for the source module
AC20TB 2m (6.56ft.) for the source module
AC30TB 3m (9.84ft.) for the source module
AC50TB 5m (16.40ft.) for the source module
AC80TB 8m (26.24ft.) for the source module
AC100TB 10m (32.81ft.) for the source module
AC05TB-E 0.5m (1.64ft.) for the source module
A6TBX36-E
A6TBY36-E
A6TBX54-E
A6TBY54-E
A6TBX70-E
AC10TB-E 1m (3.28ft.) for the source module
AC20TB-E 2m (6.56ft.) for the source module
AC30TB-E 3m (9.84ft.) for the source module
AC50TB-E 5m (16.40ft.) for the source module
Relay terminal unit A6TE2-16SRN For the sink-type output module A1SY41, A1SY41P, A1SY42, A1SH42(S1)
Cable for
connecting the relay
terminal unit
AC06TE 0.6m (1.97ft.) long
A6TE2-16SRN
AC10TE 1m (3.28ft.) long
AC30TE 3m (9.84ft.) long
AC50TE 5m (16.40ft.) long
AC100TE 10m (32.81ft.) long
Terminal block cover
for the A1S I/O
module and the
special module
A1STEC-S
Slim-type terminal block cover for the A1S I/O
module and the special module (terminal block
connector type).
All terminal block connector type modules
