3 - 1
3. SPECIFICATIONS
3 SPECIFICATIONS
The general specification common to various modules is shown.
*1 This indicates the section of the power supply to which the equipment is assumed to be
connected between the public electrical power distribution network and the machinery within
premises.
Category II applies to equipment for which electrical power is supplied from fixed facilities.
The surge voltage withstand level for up to the rated voltage of 300 V is 2500 V.
*2 This index indicates the degree to which conductive material is generated in terms of the
environment in which the equipment is used.
Pollution level 2 is when only non-conductive pollution occurs. A temporary conductivity
caused by condensing must be expected occasionally.
*3 Do not use or store the programmable controller in the environment when the pressure is
higher than the atmospheric pressure at sea level.
Otherwise, malfunction may result.
To use the programmable controller in high-pressure environment, please contact your local
Mitsubishi representative.
Item Specifications
Operating ambient
temperature
0 to 55
Storage ambient
temperature
-20 to 75
Operating ambient
humidity
10 to 90 % RH, No-condensing
Storage ambient
humidity
10 to 90 % RH, No-condensing
Vibration resistance
Conforming to
JIS B 3502,
IEC 61131-2
Frequency Acceleration Amplitude Sweep count
Under
intermittent
vibration
10 to 57Hz
–
0.075mm
(0.003inch)
10 times each
in X, Y, Z
directions.
57 to 150Hz
9.8m/s
2
–
Under
continuous
vibration
10 to 57Hz
–
0.035mm
(0.001inch)
–
57 to 150Hz
4.9m/s
2
–
Shock resistance
Conforming to JIS B 3502, IEC 61131-2 (147m/s
2
, 3 times in each of 3 directions XYZ)
Operation ambiance No corrosive gasses
Operating elevation
*3
2000m (6562ft.) or less
Installation location Control panel
Over voltage category
*1
II max.
Pollution degree
*2
2 max.
Equipment category Class I
To Next Page
