SYSTEM CONFIGURATION2.
(2) Peripheral device
Product Name Model Name Remark
Plasma hand-held
graphic programmer
A6PHP-SET
• A6PHP main unit
• SW GP-GPPA........
• SW GP-GPPK........
• SW0-GPPU................
• AC30R4......................
GPP function start-up floppy disk for the A series.
GPP function start-up floppy disk for the K series.
User floppy disk (2DD).
3m (9.84ft.)-long RS-422 cable.
Intelligent GPP A6GPP-SET
• A6GPP main unit
• SW GP-GPPA........
• SW GP-GPPK........
• SW0-GPPU...............
• AC30R4.....................
GPP function start-up floppy disk for the A series.
GPP function start-up floppy disk for the K series.
User floppy disk (2DD).
3m (9.84ft.)-long RS-422 cable.
Composite video cable AC10MD • Connection cable for the monitor display of the A6GPP screen. 1m (3.28ft.)long
RS-422 cable
AC30R4 3m (9.84ft.) long
Connection cable for between the CPU main module and
A6GPP/A6PHP.
AC300R4 30m (98.43ft.) long
User floppy disk SW0S-USER 2HD-type
Floppy disk for storing user programs
(3.5-inch, pre-formatted).
Cleaning floppy disk SW0-FDC For A6GPP/A6PHP Floppy disk for cleaning the floppy disk drive.
Optional keyboard for
A6PHP
A6KB-SET-H
• A6KB keyboard
• AC03R4H..................
• A6KB-C.....................
0.3m (0.98ft.)-long connection cable between A6KB
and A6PHP.
Key sheet for the GPP mode of A6KB.
Optional keyboard for
A6GPP
A6KB-SET
• A6KB keyboard
• AC03R4L...................
• A6KB-C.....................
0.3m (0.98ft.)-long connection cable between A6KB
and A6GPP.
Key sheet for the GPP mode of A6KB.
