4 - 41
CPU MODULE4.
3) The device numbers of input modules connected are as follows:
With respect to X440 to X45F, they are simultaneously refreshed, and set to
OFF at any time.
Do not use X440 to X45F in the sequence program.
(b) Send data storage device
1) Set the device number (Y400) for b0 of the station 1 as a send data storage
device.
2) The send data storage device occupies from Y400 to Y45F.
For the present system example, since the total number of stations is odd, it
is occupied for one extra station.
3) The device numbers of output modules connected are as follows:
With respect to Y400 to Y43F and Y458 to Y44F, they are simultaneously
refreshed, but are not output.
Stations 1 to 4 AX41C X400 to X41F
Stations 5 to 6 AJ35TB-16D X420 to X42F
Stations 7 to 8 AX40Y50C X430 to X43F
Stations 9 to 10 AX40Y50C Y440 to Y44F
Station 11 AJ35TJ-8R Y450 to Y457
POINT
(1) Set the send and received data storage devices so that device numbers are
not overlapped.
When the received data storage device is set to B0 in the system
configuration example, it occupies B0 to B5F as the device range.
Set the send data storage device to B60 or later.
When the send data storage device is set to B60, the device range will be B60
to BBF.
(2) If a bit device is specified as the send/received data storage device, the
device number set must be a multiple of 16.
(3) Device range used is (8 points) (Number of stations).
When the number of stations is an odd number, extra 8 points are necessary.
Master module
Station 2
b15
b8 b7 b0
Station 4
Station 6
Station 8
Station 10
Station 1
Station 3
Station 5
Station 7
Station 9
Station 11
X40F
X41F
X42F
X43F
X44F
X45F
X408
X418
X428
X438
X448
X458
X407
X417
X427
X437
X447
X457
X400
X410
X420
X430
X440
X450
Used by the system
A2USHCPU-S1
Output area
ddress
10
11
12
13
14
15
to
to
to
to
to
to
to
to
to
to
to
to
<Example> X0, X10, ......... X100, .........
M0, M16, ........ M256, ........
B0, B10, ......... B100, .........
