3 Replacement from FX3UC to FX5UC
3.3 Selection of Substitute Models
Extension device FX2NC-1HC FX3U-2HC
*1
The European terminal block must be replaced to
the 40-pin connector.
FX3UC-4AD FX3U-4AD
*1
The wiring must be replaced from the European
terminal block to the screw terminal block.
FX2N-5A FX3U-4AD+FX3U-4DA
*1
FX2N-2AD FX3U-4AD
*1
FX2N-8AD FX5-8AD The wiring must be replaced from the screw
terminal block to the spring clamp terminal block.
FX2N-2LC FX5-4LC The wiring must be replaced from the screw
terminal block to the spring clamp terminal block.
FX2N-2DA FX3U-4DA
*1
FX2N-1HC FX3U-2HC
*1
Replacement of the wiring from the screw terminal
block to the connector is necessary.
FX2N-10PG FX3U-1PG
*1
The open collector output is up to 200 kpps in the
recommended substitute models.
Replacement of the wiring from connector to
terminal block is necessary.
FX3U-20SSC-H FX5-40SSC-S Replacement is necessary due to the difference of
the connector type for external input connection.
FX2N-232IF No recommended substitute models
FX2N-32CCL FX5-CCL-MS Set to the intelligent device station in the
recommended substitute models.
*2
FX2N-64CL-M No recommended substitute models
FX3U-ENET No recommended substitute models Ethernet port is built into FX5UC CPU module.
FX3U-64DP-M No recommended substitute models
FX3U-32DP No recommended substitute models
FX3U-CAN No recommended substitute models
FX3U-J1939 No recommended substitute models
FX2N-10GM FX5-20PG-P It cannot be used alone.
Replacement is necessary due to the difference of
the connector type.
FX2N-20GM FX5-20PG-P It cannot be used alone.
Replacement is necessary due to the difference of
the connector type.
FX2N-1RM-SET(-E) No recommended substitute models
FX2N-32DP-IF(-D) No recommended substitute models
FX2N-64DNET No recommended substitute models
Expansion adapter FX3U-232ADP(-MB) FX5-232ADP
FX3U-485ADP(-MB) FX5-485ADP
FX3U-ENET-ADP No recommended substitute models Ethernet port is built into FX5UC CPU module.
FX3U-3A-ADP FX5-4AD-ADP+FX5-4DA-ADP
FX3U-4AD-ADP FX5-4AD-ADP
FX3U-4DA-ADP FX5-4DA-ADP
FX3U-4AD-PT-ADP FX5-4AD-PT-ADP
FX3U-4AD-PTW-ADP No recommended substitute models
FX3U-4AD-PNK-ADP No recommended substitute models
FX3U-4AD-TC-ADP FX5-4AD-TC-ADP
FX3U-CF-ADP No recommended substitute models
Extension device Recommended Substitute Models Special notes
Device name Model name Model name
