5-152
5.5 Standard Selection Functions
5.5.2 Multiplexer
MUX(_E)
(3) The value to be input to is word (signed) type data within the range from 1 to 27 (within
the range of the number of pins of variable 's').
(4) The value to be input to variable 's' is bit, word (signed), double word (signed), word
(unsigned)/16-bit string, double word (unsigned)/32-bit string, single-precision real, double-
precision real or string type data.
(5) The number of pins of variable 's' can be changed in the range from 2 to 27.
Operation result
(1) Function without EN/ENO
An operation is executed and the operation value is output from .
(2) Function with EN/ENO
The following table shows the executing conditions and operation results.
*1 When FALSE is output from ENO, the data output from is undefined.
In this case, create a program so that the data output from is not used.
EN ENO
TRUE (Operation execution) TRUE Operation output value
FALSE (Operation stop)
FALSE
*1
Undefined value
n
d
d
d
d
