Mitsubishi MELSEC Q Series Structured Programming Manual

5-188
5.9 Standard Bistable Function Blocks
5.9.2 Standard bistable function blocks (Reset-dominant)
RS(_E)
Operation result
(1) Function without EN/ENO
An operation is executed and the operation value is output from .
(2) Function with EN/ENO
The following table shows the executing conditions and operation results.
*1 The previous operation output value is held at even if EN is FALSE.
EN ENO
TRUE (Operation execution) TRUE Operation output value
FALSE (Operation stop) FALSE
Previous output value
*1
