Mitsubishi MELSEC Q Series Structured Programming Manual

5-212
5.12 Standard Timer Function Blocks
5.12.3 Off delay timer
TOF(_E), TOF_HIGH(_E)
Operation result
(1) Function without EN/ENO
An operation is executed and the operation value is output from and .
(2) Function with EN/ENO
The following table shows the executing conditions and operation results.
*1 The previous operation output value is held at and even if EN is FALSE.
EN ENO
,
TRUE (Operation execution) TRUE Operation output value
FALSE (Operation stop) FALSE
Previous output value
*1
d1
d2
d1
d2
d1
d2
