Mitsubishi MELSEC Q Series Structured Programming Manual

Appendix 2 Correspondence between Devices and Addresses
App-7
A
APPENDIX
Table App. 2-2 Correspondence between devices and addresses
Device
Expressing method
Example of correspondence between
device and address
Device Address Device Address
Step relay S
Sn %MX2.n S127 %MX2.127
SFC transition device TR
TRn %MX18.n TR3 %MX18.3
SFC block device BL
BLn %MX17.n BL3 %MX17.3
Link input
J
Jx\Xn %IX16.x.n J1\X1FFF %IX16.1.8191
Link output
Jx\Yn %QX16.x.n J1\Y1FFF %QX16.1.8191
Link relay
Jx\Bn %MX16.x.1.n J2\B3FFF %MX16.2.1.16383
Link register
Jx\Wn
%MW16.x.1.n
%MD16.x.1.n
J2\W3FFF
%MW16.2.1.16383
%MD16.2.1.16383
Link special relay
Jx\SBn %MX16.x.11.n J2\SB1FF %MX16.2.11.511
Link special register
Jx\SWn
%MW16.x.11.n
%MD16.x.11.n
J2\SW1FF %MW16.2.11.511
File register ZR
ZRn
%MW12.n
%MD12.n
ZR32767
%MW12.32767
%MD12.32767
