(c) Linear servo motor control mode/DD motor control mode
Cumulative feedback
pulses
(Note)
Unit total power
consumption 2
(increment of 100 kWh)
Electrical angle high
Electrical angle low
Electrical angle high
Cumulative feedback pulses
Z-phase counter low
Z-phase counter high
Note. The displays in the frames are the standard control modes in one cycle with some
displays omitted.
