11. OPTIONS AND AUXILIARY EQUIPMENT
11 - 33
11.3.4 Dimensions
(1) FR-BU2-(H) Brake unit
[Unit: mm]
FR-BU2-15K
Rating
plate
68
6 56 6
5
5 118
5
128
18.5
52 62
4
132.5
φ5 hole5 hole
(Screw size: M4)
[Unit: mm]
FR-BU2-30K/FR-BU2-H30K
129.5
5
59
18.5
Rating
plate
52
2-φ5 hole
(Screw size: M4)
128
55 118
5
108
6
6
96
[Unit: mm]
FR-BU2-55K/FR-BU2-H55K/FR-BU2-H75K
18.5
Rating
plate
52 72
5
142.5
128 118 55
5
61586
170
2-φ5 hole
(Screw size: M4)
