11. OPTIONS AND AUXILIARY EQUIPMENT
11 - 64
(2) 400 V class
W1
D2
W ± 2.5
H ± 2.5
D or less
(D3)
D1 ± 1
4-d mounting hole (Note 1)
PP1
Fig. 11.4
W1
W ± 2.5
D2
D1 ± 1
H ± 2.5
PP1
D or less
(D3)
4-d mounting hole (Note 1)
Fig. 11.5
H ± 2.5
W1
W ± 2.5
D2
D1 ± 1
PP1
D or less
(D3)
4-d mounting hole (Note 1)
6
Fig. 11.6
(Note 2)
Servo amplifie
r
P3
P4
FR-HEL-H
5 m or less
Note 1. Use this for grounding.
2. When using the power factor improving DC reactor, remove the short bar across P3 and P4.
